Request a quote on stock# 3446| Specification | Description |
|---|---|
| Maximum capacity: Straight Cut (90°) | 14 in. x 14 in. |
| Maximum capacity: At a 45° Angle | 9 in. x 14 in. |
| Standard length gauge | 0 to 20 in. |
| Width of vise table: | |
| Overall | 20-1/4 in. |
| Receiving side | 9-3/8 in. |
| Cut-off side | 10-7/8 in. |
| Height - Floor to Vise Table | 29-1/8" |
| Speed range - approx. strokes per minute | 3 speeds 50-85-125 |
| Length of stroke | 6 in. |
| Overall Size | 32" F-B 74" L 73" H |
| Length of saw blade* | 18 in. or 21 in. |
| Motor | 5 H.P. 230v 3ph |
| Approximate Weight | 4000 lbs. |
