Plate Capacity:
Length...................................................144" (maximum)
Width......................................................6" (minimum) (no maximum)
Thickness...............................................0-8" (maximum)
Travel of Saw Head......................................0-144" (nominal)
Blade Speed (Variable)................................55-350 F.P.M.
Blade Tension Control.................................
Wheel Diameter...........................................30"
Throat Depth...............................................29"
Base Construction........................................
Blade Width Capacity..................................1", 1 1/2" & 2"
Blade Length................................................204"
Table Size (Main).........................................86" x 144" (nominal)
Table Capacity (Main)..................................12,000 lbs (est.)
Upper Wheel Adjustment..............................4" (nominal)
Guide Post Size............................................1 7/16" x 4"
Table Height.................................................41 1/4" (from floor)
Motor Variable Speed Band Saw Drive.........5 HP
Extra New Blades
Hydraulic Hold-Down System
Cut Watch System
Automatic Stock Indexing
Heavy Duty Blade Guides
Complete Electrical Controls with Operator's Control Station
Traveling Head with Dual Precision Guide Rails and Power Feed
Power Guide Post Adjustment
Mist Coolant System
Overall Dimensions.......................................22' L-R x 14' F-B x 8'6" High (est.)
Weight..........................................................14,000 lbs. aprox.
LINK TO SHORT VIDEO OF MACHINE
http://youtu.be/c6_qtpbtQrU
ALSO NEW MACHINE LINK TO MFG
http://www.tannewitz.com/tannewitz-products/Metal-Working-Bandsaws/Auto-Indexing-Saws/3000MH8.aspx New Price aprox $250k
Request a quote on stock# 3262
