Request a quote on stock# 4143| Specification | Description |
|---|---|
| CAPACITIES: | |
| SWING OVER BED 15" | |
| SWING OVER CROSSLIDE 9" | |
| DISTANCE BETWEEN CENTERS 32" | |
| HEADSTOCK: | |
| SPINDLE NOSE CAMLOCK | |
| SPINDLE BORE 2-1/4" | |
| 12 SPINDLE SPEEDS (RPM) 45-1800 RPM | |
| THREADS & FEEDS: | |
| 48 INCH THREAD CHANGES 2 - 112 TPI | |
| 35 METRIC THREAD CHANGES .25 - 14 MM | |
| 48 INCH FEED CHANGES .0018 - .104 IPR | |
| 48 METRIC FEED CHANGES .05 - 2.6 MMPR | |
| TAILSTOCK: | |
| CENTER (TAPER) MT #4 | |
| MOTOR 7.5 HP | |
| VOLTAGE 460/3PHASE | |
| MACHINE DIMENSIONS: | |
| FLOOR SPACE 76" L X 42" W X 56" H | |
| NET WEIGHT (approx) 4,000 LBS. |
